| Power | 30W |   |
| Material | Die-cast Aluminum | |
| LED Chip | Luxeon 3030 | |
| Light Efficiency | >100lm/W | |
| CCT: | 3000-6500k | |
| Viewing Angle： | 120° | |
| IP | 65 | |
| Working Environment: | 30℃~+70℃ |
| Module | 100W |  |
| Encapsulation | Glass/EVA/Cells/EVA/TPT | |
| Efficiency of solar cells | 18% | |
| Tolerance | ±3% | |
| Voltage at max power(VMP) | 18V | |
| Current at max power(IMP) | 5.56A | |
| Open circuit voltage(VOC) | 22V | |
| Short circuit current(ISC) | 5.96A | |
| Diodes | 1by-pass | |
| Protection Class | IP65 | |
| Operate temp.scope | -40/+70℃ | |
| Relative humidity | 0 to 1005 | |
| Warranty | PM is not less than 90% in 10 years and 80% in 15 Years |
| Rated Voltage | 12.8V | | |
| Rated Capacity | 38.5 Ah | ||
| Approximate Weight(kg, ±3%) | 6.08KG | ||
| Terminal | Cable（2.5mm²×2 m） | ||
| Maximum Charge Current | 10 A | ||
| Ambient Temperature | -35~55 ℃ | ||
| Dimension | Length (mm, ±3%) | 381mm | |
| Width (mm, ±3%) | 155mm | ||
| Height (mm, ±3%) | 125mm | ||
| Case | Aluminum | ||
| Warranty | 3year | ||
| Rated working voltage | 10A DC12V |  |
| Max. discharging current | 10A | |
| Max. charging current | 10A | |
| Output voltage range | Max panel/ 12V 150WP solar panel | |
| The precision of constant current | ≤3% | |
| Constant current efficiency | 96% | |
| levels of protection | IP67 | |
| no-load current | ≤5mA | |
| Over-charging voltage protection | 12V | |
| Over-discharging voltage protection | 12V | |
| Exit over-discharging voltage protection | 12V | |
| Turn on voltage | 2~20V | |
| Size | 60*76*22MM | |
| Weight | 168g | |
| Warranty | 3years |
| Material | Q235 |
|
| Height | 6M | |
| Diameter | 60/160mm | |
| Thickness | 3.0mm | |
| Light Arm | 60*2.5*1200mm | |
| Anchor Bolt | 4-M16-600mm | |
| Flange | 280*280*14mm | |
| Surface Treatment | Hot dip galvanized+ Powder Coating | |
| Warranty | 20 Years |
Over 15 years of solar lighting manufacturer,engineering and installation specialists.12,000+Sqm Workshop 200+ Worker and 16+ Engineers200+ Patent TechnologiesR&D CapabilitiesUNDP&UGO SupplierQuality Assurance + Certificates OEM/ODM One Head Group With 2 Factories, 5 SubsidiariesOverseas Experience in Over 126 Countries
